UGR Accessory Family for Modular Lens Systems
The UGR family offers different 12 models dedicated to MODULARIS, the most complete modular lens systems.
UGR accessories, are available in diverse arrays enabling the housing of 6 to 9 lenses and are created in different shapes: round, linear, square.
UGR accessories, made of black PC, are designed to reduce glare from the lighting fixtures. Optimized for modularis series, UGR accessories deliver the opportunity to realize unique lighting applications where glare can be a serious problem. UGR accessories are easily assembled onto the modularis systems by two screws. This type of fastening, simple and fast, ensures the perfect matching between the UGR accessories and the modularis systems. UGR ACCESSORIES assembled with MODULARIS OPTICAL SYSTEMS offer so many innovative solutions able to meet specific dimensional requirements and special assembly needs while drastically reducing glare.
Our UGR accessory family is designed to reduce glare from the lighting fixtures.
The UGR accessories are available in different arrays enabling the housing of 6 to 9 lenses.
The UGR accessories are made of black PC.
KE1423UGR
7 lens positioning
Ø 88.89 mm
h 9.25 mm
KE1424UGR
9 lens positioning
Ø 88.89 mm
h 9.25 mm
KE1550UGR
6 lens positioning
167.53 mm x 27.83 mm
h 9.25 mm
KE1551UGR
9 lens positioning
83.72 mm x 83.72 mm
h 9.25 mm
Typical Applications:
Indoor Lighting: architectural and general lighting, ceiling mounted luminaires, recessed fixtures, spotlights, industrial, commercial, lowbay lighting, NEMA, office, retail and supermarkets, task lighting, warehouse lighting.
